1. Brief Description
Original vibration plate price rise and fall (single-person operation, adjusted within five minutes, no need to move the adjustment foot cup)
2. Main technical parameters
| model | DHGX011F |
| power supply | 220V 50/50HZ |
| power | 2KW |
| Gas source | 0.4-0.6Mpa |
| Filling volume | 0.15-1g (standard screw) |
| Other filling volumes | 1-3g (with screw) |
| Filling volume instructions | The compatible range cannot exceed 3g |
| Number of filling heads | 1 |
| Filling drive | Servo Motor |
| Filling mode | Screw |
| speed | 25-35 bottles/minute |
| Suitable bottle height | 27-50mm (other specifications can be customized) |
| Suitable bottle diameter | Customized specifications (different diameters are not universal) |
| Accuracy | 3-5%, except for mixed materials |
| conveyor | |
| Bottle unscrambler | have |
| weight | 300kg |
| Filling lifting method | Cylinder (servo optional) |
| Adapt to cover | Pure aluminum cover, aluminum-plastic cover, pure aluminum cover |
| Adapt to inner plug | Butyl rubber plug, rubber plug, silicone plug |
