DS-15 fully automatic strapping machine
1. Brief description
This machine uses imported electrical components, PLC control system, human-machine interface, and has the characteristics of stable operation and simple operation; it is mainly used for combined bundling of boxed products in the food and pharmaceutical industries.
2.Main technical parameters
Model | DS-15 |
Bale size (LxWxH) Max | 190*150*300mm |
Bale size (LxWxH) Min | 50x60x90mm |
Use packaging materials | PE film |
Applicable strapping specifications (width) | 30~80mm |
Bale film thickness | 30~80um |
Baling speed | 8~15 bundles/min (depending on the box size and number of layers) |
Working power supply | 220V/50Hz |
Equipment power | 800W |
Working air pressure | 0.6~0.8MPA |
Dimensions | 1000x800x1600mm |
Conveying size | 800x250x800mm |
Total equipment weight | 350kg |
