DS-25 fully automatic strapping machine
1.Brief description
This machine uses imported electrical components, PLC control system, human-machine interface, and has the characteristics of stable operation and simple operation; it is mainly used for the combination and bundling of boxed products in the food and pharmaceutical industries.
2. Main technical parameters
Model | DS-25 |
Bale size (LxWxH) Max | 190*150*300mm |
Bale size (LxWxH) Min | 50x60x90mm |
Packaging material | PE film |
Applicable cable tie specifications (width) | 30~80mm |
Bundling film thickness | 30~80um |
Bundling speed | 15~28 bundles/min (depending on the box size and number of layers) |
Working power | 220V/50Hz |
Equipment power | 1500W |
Working air pressure | 0.6~0.8MPa |
Dimensions | 1100x800x1600mm |
Conveying size | 1300x250x800mm |
Total equipment weight | 500kg |
